Installation
D397-21-880 Issue G
3 Installation
3.1 Unpack and inspect
Remove all of the packaging material and check the Controller. If the Controller is damaged, follow the Edwards
return of equipment procedures that are laid out in the back of this manual. Do not use the Controller if it is
damaged.
Check that your package contains the items that are listed in Table 6. If any of these items are missing, notify your
supplier in writing within three days. If the Controller is not to be used immediately, store the Controller in suitable
conditions as described in Section 6.1.
3.2 Fitting the controller
CAUTION
Rubber feet must be fitted (Figure 5, item 1) so that there are correct clearances for air circulation. If you do
not, the performance of the Controller may be affected at high operating temperatures.
The Controller can be used on a bench-top or can be fitted in a rack or cabinet. Figure 5 shows the dimensions of the
TIC that are required for bench top use.
Note: If the interlocks are not used the logic interface adaptor must be fitted to the 25-way connector.
Table 6 - Component checklist
Quantity Description Check (
9)
1 Controller
1 Quick Guide and Health and Safety Information
1TIC CD
2 Rear non-slip feet
1 Logic interface plug
1 Analogue output mating half connectors
WARNING
If access to the IEC connector is restricted an additional isolation device should be provided, which
will be easily accessible by an operator.
