Technical data
D397-21-880 Issue G
2Technical data
2.1 Electrical data
2.2 Operating and storage data
2.3 Mechanical data
2.4 Connections
2.4.1 Active gauge connectors
Connector type CEE/IEC 320
Electrical supply 90 to 264 V a.c. 47 to 63 Hz
Power consumption
TIC Instrument Controller 55 VA maximum (D397-00-000)
Peak inrush current 5 A at 110 V a.c D397-00-000
12 A at 240 V a.c D397-00-000
Fuse The unit is self-protecting and has no user replaceable
fuse. The unit will recover once any overload is removed.
Earth Stud M4
Ambient operating temperature range 0 °C to 40 °C
Ambient storage temperature range -30 °C to 70 °C
Maximum ambient operating humidity Max 90% RH non condensing at 40 °C
Maximum operating altitude 3000 m max
IP rating 20
Weight
TIC Instrument Controller 1.3 kg
Connector type FCC/RJ45, 8-way (refer to Figure 1)
Power supply 24 V d.c.
Maximum power rating 21 W total for the three gauges
Input voltage range -0.5 V to 15 V
Output ID current 33
µA, 0 V to 13 V
Control output active: <0.8 V d.c. (2 mA max)
inactive: open (internal pull-up to 24 V)
Control input low: <2.0 V d.c. (I
out
<160 µA)
high: >3.5 V d.c. (internally pulled up to 24 V)
