D135-10-880C - Operation
Page 61
Calibration
Main menu > Calibration
In the menu Calibration, Figure 29, the selection between internal and external calibration
can be chosen.
Refer to Calibration for a detailed description of the calibration.
Figure 29 Display: calibration menu
Settings
Main menu > Settings
This menu, Figure 30, allows to observe and to change the adjustment of the internal
machine settings.
Figure 30 Display: settings menu
Key No. Name Description
1 Back Return to the main menu.
2 Vacuum settings Settings of vacuum system related functions
(see Vacuum settings).
3 Filter and
Background
See Filter and background.
4 Mass Switching between Helium and Hydrogen
(see Mass).
5 Interfaces Settings for electrical communication and selection for
control location (see Interfaces).
