M561-00-880 Issue
C
Page 18
© Edwards Limi
ted 20
12. All rights reserved.
Edwards and the Edw
ards logo are trad
emarks of Edwar
ds Limited.
Technical data
T
able 12 - Cooling water supply te
mperature
Cooling water supply temperature
Units
Applies to pump models
10 - 30
°C
iXH100
iXH200H
iXH610
iXH1210/H
iXH1220H/T
iXH1820/H/T
iXH3030/T
iXL250Q
10 - 25
°C
iXH450H
iXH500H
iXH3045H
iXH3050H
iXH4545HT
iXH4550HT
iXH6045H/T
iXH6050H/T
pXH4500
pXH6000
iXL500Q
iXL500R
iXL750Q
iXL750R
29
31
