Edwards iXH3030T User Manual

© Edwards Limited 2012. All rights reserved. Page 59
Edwards and the Edwards logo are trademarks of Edwards Limited.
Appendix A1
M561-00-880 Issue C
By default the 4 parameters displayed in the Normal menu are as shown above for the iXH, these may be changed via
the Edit Display attributes menu, accessed from the SETUP menu. For the pXH, the default Normal menu is as shown
below.
A1.4.2 Status menu
Press the Status button to enter. Scroll by pressing up/down keys. Press CANCEL to exit back to Normal menu.
If a device is not fitted the associated parameters will not be displayed. Parameters displayed:
Table A4 - Normal menu
Description Typical Display
Serial Number S/N 1234567
Control Holder NONE IN CONTROL
pXH booster current PB CURRENT 1.1A
Dry pump current DP Current NP
Table A5 - Status menu
Description Typical Display
Serial Number
*
S/N 1234567
Control Holder NONE IN CONTROL
Dry Pump current DP CURRENT 1.1A
Booster current MB CURRENT 1.1A
pXH Booster current PB CURRENT 1.1A
Green Mode state GREEN MODE STATE Off
Gate valve open/closed state GATE VALVE Open
Remote Gate valve open/closed state PB VALVE Open
Dry pump stator reference temperature TCS REF 100C
Dry Pump temperature DP TEMP 100C
Dry Pump exhaust stage temperature DP EXH STG 100C
Dry Pump End Cover temperature DP E/C TEMP 100C
Dry Pump temperature 2 DP TEMP 2 100C
Booster Temperature MB TEMP 100C
Booster MB End Cover temperature MB E/C TEMP 100C
pXH Booster Temperature PB TEMP 100C
pXH End cover Temperature PB E/C TEMP 100C
N
2
Flow Rate N
2
FLOW 44 slm
Dry Pump Power DP POWER 1.1 kW
Booster Power MB POWER 1.1 kW
pXH Booster Power PB POWER 1.1 kW
Dry Pump speed in percent DP SPEED 100 %
Dry Pump speed in Hz DP SPEED 100 Hz
Booster speed in percent MB SPEED 100 %
Booster speed in Hz MB SPEED 100 Hz
pXH Booster speed in percent PB SPEED 100 %
