Edwards LaserSense Nano

Chapter 2: Installation and configuration
12 LaserSense Nano Aspirating Smoke Detector Installers Handbook
Figure 5: Installation with detector mounted in ceiling void (no exhaust piping)
(1)
(2)
(4)
(3)
(1) Sampling pipe
(2) Sampling hole
(3) Detector
(4) False ceiling
