MaxLoader User’s Guide
36
• H/W Rev : Hardware revision number for your programmer
• S/W Rev : Current MaxLoader software revision number
• Serial No : Serial number of MaxLoader hardware
(Additional Option Information for Non PLD Devices)
The following information presents programming information of the selected
device.
• Algorithm : Programming Algorithm
• Vccp : Main Power Supply Voltage
• Vpp : Programming Power Supply Voltage
• Tpwp : Programming Pulse Width
System Information
• Device Name : The current device number with manufacturer name
• Device Size : The size of device in HEX value
(Ending Address –Starting Address + 1)
• Free Disk : Check the free disk space for a big size E(E)PROM
programming.
• Adapter : Optional Adapter Name for Non-standard devices
• Pins : Number of device pin
• File : Current working directory path and file name after
loading a file
Counter
• Devices/HR : Displays the estimated number of devices that can be
programmed per hour. This feature can only be used
when choosing the Program or Auto selection under
the Device button.
• Success: This number indicates the device programmed
successfully.
• Failure: This number indicates the number of device
programming errors that occur during a programming cycle.
These could be either Blank Checking, Programming, or
