MaxLoader User’s Guide
81
CURSOR AT LOCATION: 00000000 8 BIT ADDRESSING
HEXADECIMAL ASCII
ADDRESS -0 -1 -2 -3 -4 -5 -6 -7 -8 -9 -A -B -C -D -E -F 0123456789ABCDEF
00000000 01 23 45 67 89 AB CD EF 00 11 22 33 44 55 66 77 .#Eg . . ”3Duf w
00000010 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
Example #1: Programming one 16-bit device (Data word width = 16, Odd/even
byte swap = disabled)
The user data is allocated as follows:
Device
MSB LSB
Device Address: 0 23 01
1 67 45
2 AB 89
3 EF CD
Sample data file (Motorola EXORmacs Format, Code 87):
S00B00004441544120492F4FF3
S11300000123456789ABCDEF001122334455667750
S9030000FC
Data file opened with format 87 and displayed in the editor (8-bit addressing
mode):
CURSOR AT LOCATION: 00000000 8 BIT ADDRESSING
HEXADECIMAL ASCII
ADDRESS -0 -1 -2 -3 -4 -5 -6 -7 -8 -9 -A -B -C -D -E -F 0123456789ABCDEF
00000000 01 23 45 67 89 AB CD EF 00 11 22 33 44 55 66 77 .#E.g. . . ”3DUf w
00000010 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
Example #2: Programming one 16-bit device (Data word width = 16, Odd/even
byte swap = Enabled)
The user data is allocated as follows
