EEC 6500 Series - Page 11

5
Dimension (W x H x D), mm
11
430 x 472
(579) x 650
(730)
430 x 732
(839) x 650
(730)
600 x 972
(1079) x 900
(980)
600 x 972
(1079) x 900
(980)
800 x 1557
(1662) x 900
(980)
800 x 1557
(1662) x 900
(980)
Dimension (PFC)(W x H x D),
mm
11
430 x
602(709) x
650 (730)
430 x 732
(839) x 650
(730)
600 x 972
(1079) x 900
(980)
600 x 972
(1079) x 900
(980)
800 x 1557
(1662) x 900
(980)
800 x 1557
(1662) x 900
(980)
Weight
128 kg
198 kg
397 kg
450 kg
600 kg
800 Kg
Weight (PFC)
228 kg
350 kg
592 kg
663 kg
885 kg
1000 Kg
* Product specifications are subject to change without notice.
1. When output voltage < 30 V, ADJ = ON can be meet this spec.
2. Maximum current when output voltage at 120 / 240 V
3. Maximum current when output voltage at 140 / 280 V
4. Maximum current when output voltage at 240 / 480 V
5. Only one option can be selected among optional output frequency 45 - 500Hz and 400 / 800Hz
6. < 1.2% for < 47Hz at output voltage within the 110 - 140 V at Low Range or the 220 - 280 V at High Range (incl. 45 - 500Hz)
< 1% for ≥ 47Hz at output voltage within the 110 - 140 V at Low Range or the 220 - 280 V at High Range (incl. 45 - 500Hz)
< 1.2% for output voltage within the 220 - 280 V at Low Range or the 440 - 560 V at High Range (option 0 - 600V)
< 1.5% for < 47Hz at output voltage within the 220 - 280 V at Low Range or the 440 - 560 V at High Range (option 0 - 600V & 45 - 500Hz)
< 1.2% for ≥ 47Hz at output voltage within the 220 - 280 V at Low Range or the 440 - 560 V at High Range (option 0 - 600V & 45 - 500Hz)
7. Max. Current without PFC Function
8. a. When output frequency ≥ 100 Hz & ≤ 500 Hz & N-G short, the current meter guarantee minimum current from 0.01 A
b. When output frequency ≥ 500 Hz & N-G short, the current meter guarantee minimum current from 0.02 A
c. When output frequency ≥ 100 Hz & ≤ 500 Hz & N-G short, the current meter guarantee minimum current from 0.02 A at 600 V models.
d. When output frequency ≥ 500 Hz & N-G short, the current meter guarantee minimum current from 0.03 A at 600 V models
9. At Voltage > 5 V for 0 - 300 V; At Voltage > 10 V for 0 - 600 V (option)
10. Only one interface can be selected among RS232 & USB, GPIB, Analog card
11. Figure in parentheses are maximum values with fixture stand
【Ordering Information】
• 6510 High Power Programmable AC Power Source 0 - 300 V / 45 - 70Hz (10 kVA)
• 6510P High Power Programmable AC Power Source 0 - 300 V / 45 - 70Hz (10 kVA) with PFC
• 6520 High Power Programmable AC Power Source 0 - 300 V / 45 - 70Hz (20 kVA)
• 6520P High Power Programmable AC Power Source 0 - 300 V / 45 - 70Hz (20 kVA) with PFC
• 6530 High Power Programmable AC Power Source 0 - 300 V / 45 - 70Hz (30 kVA)
• 6530P High Power Programmable AC Power Source 0 - 300 V / 45 - 70Hz (30 kVA) with PFC
• 6540 High Power Programmable AC Power Source 0 - 300 V / 45 - 70Hz (40 kVA)
• 6540P High Power Programmable AC Power Source 0 - 300 V / 45 - 70Hz (40 kVA) with PFC
• 6560 High Power Programmable AC Power Source 0 - 300 V / 45 - 70Hz (60 kVA)
• 6560P High Power Programmable AC Power Source 0 - 300 V / 45 - 70Hz (60 kVA) with PFC
• 6580 High Power Programmable AC Power Source 0 - 300 V / 45 - 70Hz (80 kVA)
• 6580P High Power Programmable AC Power Source 0 - 300 V / 45 - 70Hz (80 kVA) with PFC
• Opt.608 600 V AC Output for models 6510 & 6520 & with PFC models
• Opt.609 600 V AC Output for models 6530, 6540, 6560, 6580 & with PFC models
• Opt.616 Output Frequency 45 - 500 Hz Full Range Adjust for models 6510 & with PFC models
• Opt.650 Remote Sensing
• OPT.668 suppression Input Voltage
• OPT.671 RCP function for models 6510, 6520, 6530 & with PFC models
