EEC 6500 Series - Panel Description

10
3.2 Panel Description
A. 14U’S REAR PANEL
7. Output Circuit Breaker
8. Input Circuit Breaker
9. Input Supply Terminal
10. Output Terminal
11. PLC Remote D-Type Connector
12. High-Speed Ventilation Fans
1. Handle
2. Caster Wheels
3. Front Panel Output Switch
4. Universal AC Output Socket (15A)
5. Input Power Switch
6. Ventilation Inlet
1
1
2
2
2
2
3
4
5
11
10
6
7
9
12
8
6
