EEC 6500 Series - Page 17

11
B. 17U’S PANEL DESCRIPTION
7. Output Circuit Breaker
8. Input Circuit Breaker
9. Input Supply Terminal
10. Output Terminal
11. PLC Remote D-Type Connector
12. High-Speed Ventilation Fans
1. Handle
2. Caster Wheels
3. Front Panel Output Switch
4. Universal AC Output Socket (15A)
5. Input Power Switch
6. Ventilation Inlet
1
1
2
2
3
4
5
6
2
2
6
8
7
12
9
10
11
