27. T Indicator. When this LED is ON, the MULTIMETER display shows the time duration.
28. P-S Indicator. When this LED is ON, the MULTIMETER display shows the current memory of
Program-Step.
29. AUTO Indicator. Indicates the output is at Auto ranging mode.
30. MANUAL Indicator. Indicates the output is at Manual ranging mode.
31. FAIL Indicator. When the LED is ON, it is at abnormal operation.
32. PROTECT Indicator. When the LED is ON, there is a protection at abnormal operation.
33. P1 Indicator. When the LED is ON, the output is set according to P1.
34. P2 Indicator. When the LED is ON, the output is set according to P2.
When the LED is ON with P1 and P2, the output is set according to P3.
35. SYSTEM Indicator. Indicates the current setting mode is at SYSTEM parameter setting.
36. PROGRAM Indicator. Indicates the current setting mode is at PROGRAM parameter setting.
37. Voltage High Range Indicator. When the LED is ON, the output is set to high range.
38. Voltage Low Range Indicator. When the LED is ON, the output is set to low range.
