D. 28U’S PANEL DESCRIPTION
1. Handle
2. Caster Wheels
3. Front Panel Output Switch
4. Universal AC Output Socket
(Trip Current: 15A)
5. Input Power Switch
6. Ventilation Inlet
7. Output Circuit Breaker
8. Input Circuit Breaker
9. Input Supply Terminal
10. Output Terminal
11. PLC Remote D-Type Connector
12. High-Speed Ventilation Fans
