31
Basic Commands:
Command
Value
Description
TD?
By PHASE
FREQ,VOLT,CURR,WATT,PF,TIMER
TEST
Power On
RESET
Power Off
METER X
0
Power Reading
1
Power Factor Reading
2
Timer Reading
3
Program -Step
METER?
Displayed parameter of meter Query
RANG X
0
Low 0 - 150V (or 0=Low 0-300V)
1
High 0 - 300V (or 1=High 0-600V)
RANG?
Setting Range Query
* The format of acknowledgement is “Frequency, Voltage, Current, Watt, PF, Time”
Program Commands:
COMMAND
Value
Description
PROG X
0 - 8
Program Number
PROG?
Program Number Query
AR X
0
Auto Run Off
1
Auto Run On
AR?
Auto Run setting Query
LC XXXX
0
Loop Cycle “Continuous”
1
Loop Cycle “Once”
2 - 9999
Loop Cycle 2 - 9999
LC?
Loop Cycle Query
STEP X
1 - 5
Step Number
STEP?
Step Number Query
VOLT XXX.X
0.0 - 300.0
Voltage
VOLT?
Voltage Query
FREQ XXX.X
47.0 - 630.0
Frequency (Option 45.0-500.0 or 400Hz)
FREQ?
Frequency Query
DELAY XXXX
0 - 9999
Delay Time
DELAY?
Delay Time Query
DWELL XXXX
0 - 9999
Dwell Time
DWELL?
Dwell Time Query
CHI XXX.X
0.0 - max. A
High limit Current
