Connection – Page 91
Solar inverter | V1.7
 If the communication between the
inverter and the battery is successful, the
battery symbol blinks
on the LCD display.
9.8.3.3 Installing battery type SOLTARO
Step 5
©
Use a specially manufactured RJ45 cable to
connect the inverter and the lithium battery.
Step 6
Open the DC circuit breaker and switch on
the lithium battery.
Step 7
Switch the inverter on.
