Short circuit monitoring – This function monitors the 4

output ports individually while using mains power, and the total load while using

battery power (15 A / DC per size).

If a short circuit occurs while using mains power, the output port fuse shall fail 5

A/FF (breaks at 11 A on.4 sec (2530 VA / W).

Saturation (power stage protection) – This function

monitors that the power stage MOSFETs open properly. If opening incorrectly,

the inverter will stop and an alarm will be displayed. This may sometimes happen

at large start currents, or if one or several transistors are damaged. This way, no

further damage can occur.
