U S E R M A N U A L E P S - D
Technical specifications and data are subject to change without any prior notice.
32
Specifications
Charger:
Voltage: 230 VAC +-10 %
Frequency: 50Hz +-2 %
Protection: Mains fuse/Battery fuse/Output fuse/Polarity protection for the
battery (Diode), DC Overvoltage & Deep discharge.
Battery Charge Current: C/10 A/DC – automatically set through battery size.
Battery Voltage: 24 Vdc.
Battery voltage adjustment: 27.4 Vdc +-0.1% - adjustable through
potentiometer.
Low battery alarm: 22.0 Vdc (reset at 25.5 Vdc).
Under voltage shutdown, battery: 19 Vdc (reset at 24.2 Vdc).
Temperature compensation: Checks and adjusts the charging voltage.
Inverter:
Voltage: 220/230/240VAC
Static Adjustment: +-2% True RMS (Selected software) - 90 % of nominal
when low battery.
Dynamic Adjustment: max 10% - return to nominal < 5 seconds
Frequency: 50 Hz +-0.1 %- own crystal – under mains fail50 Hz +-2% - when
mains present.
Slew rate: 0.1 Hz/second
Curve form: Quasi (modulated square ) or sine.
Under voltage shutdown: 150 Vac.
Overload while Mains powered: The rated size. EPS600D = 600 VA
Overload while battery powered: 180 W per size +50 W for own power (while
the out voltage exceeds 150 Vac) e.g. EPS750D =5x180+50=950 W.
