U S E R M A N U A L E P S - D
Technical specifications and data are subject to change without any prior notice.
33
Short circuit while mains powered: Fuse fail 5 A/FF (breaks at 11 A on.4 sec
(2530 VA / W)
Short circuit while battery powered: 240% for EPS10D – EPS60D, 210% on
EPS80D, 170% on EPS100D, (within 0.4 sec.) or fuse break depending on what
comes first.
Alarm – Two connections are placed next to the heatzinks. The third is placed
above the processor.
Relay contact data: 1A @ 24 Vdc or 0,24 @ 125 Vac.
All contacts drawn in normal position. (in normal operation, under voltage,
without alarm).
• INV. = Inverter mode ( Battery mode), due to the fact that the
unit has entered inverter mode and is being powered from the
battery.
• LOAD = Load error. Caused by earth leakage, overload or short
circuit.
• COMMON= Summary alarm. Caused by any above errors and fire
alarm.
Display
• Dot Matrix display – 2 lines x 16 characters.
• 4 LED – Mains power / Charge error / Battery power/ Test
ongoing
• Buzzer active during all active alarms, if chosen.
• Clock – accuracy <1 minute/ month at 20°C.
Functions
• Battery Test Function – selectable through the software.
• Sleep function during lengthy power outage – automatic restart.
• Fuse monitoring – control of the output fuses
• Load monitoring – selectable through software weekly / monthly.
• Earth leakage monitoring- reacts to 30 mA (or 100 mA / 300 mA)
reaction time <0.4 sec.
Switch-off time < 0.4 seconds. factory set to 30 mA.
• Fire alarm functions. May be integrated in existing monitoring
systems (BMS)
• Energy saving for night-time switch-off
Environment / Encasing
• Temperature range: 10°C - 30°C.
• Relative humidity: 40% - 90% non-condensed.
• Altitude: 1000 m maximum.
• Steel encasing / Powder enameled IP23.
