U S E R M A N U A L E P S - D
Technical specifications and data are subject to change without any prior notice.
26
**Testday – if automatic battery testing has been selected under “Setting
routine” ( or factory set), otherwise, choose EBS size. Test date weekday.
**TestTim – indicates the time when the automatic test will begin. NOTE
The test will begin within 1 minute of set time, and will last for 30 minutes.
Unit Size – indicates the unit size in Watts, compare with the load table and
data plate.
Batt – indicates the battery capacity, must correspond to existing battery (in
relation to temperature) to prevent battery overcharge/undercharge.
Next annual test – indicates the date of the next annual test (automatic
scrolling)
Las annual test – indicates the date of the previous successful (1 hour use)
annual test.
If no successful tests exist, the display will indicate *****************.
(automatic scrolling)
Fire-alarm 1/2/3 – indicates type of selected fire alarm.
Effekta Power Syst. +4640946020 – Shows Company name and number
Date/Month/Year/Day – indicates current date.
Time – indicates current time, equipped with summer/winter crossover.
** Only visible when autotest has been selected.
LEDs – On the front there are placed 4 LEDs, for a simple overview.
Mains power – green: The mains voltage exceeds 80 % of the standard 230
Volts and the frequency is 50Hz ± 2%.
Charger Fault – red: Mains below 65 % (during 5 ms or longer) and has not
returned to >80 %, or battery over voltage (>28.5 V DC). This should also
activate if the charger experience an internal charger problem.
Battery Mode – red: The inverter is running. This can be due to mains failure or
an autotest. If it’ due to mains failure, this LED diode will be lit up when the
mains returns and while the unit is synchronising with the mains.
The unit will then make a pause for 4 seconds, during which time the mains must
be stable.
TEST - red : The unit is auto-testing
