8. Starting up the UPS System
To ensure error-free start-up, the following points are to be observed:
1. Connect the UPS, with the provided connection cable, to the
mains.
2. Wait until the system test has been concluded.
3. Switch on the UPS by pressing the previously described key combination
(or "POWER ON/OFF").
4. Wait until the UPS is in the mains operating mode.
5. Now switch on the loads successively and observe the load display.
If all the steps have been completed successfully, the UPS must be in the
mains operation mode and the load display should amount to less than 100 %.
6. Now switch off the system (key combination "OFF" or
"POWER ON/OFF").
7. Please wait a few seconds ("refresh").
8. Start the UPS again.
The UPS system should again be in the mains operating mode after the indi-
cated length of 10 sec. This test ensures that the systems will also start with
the connected total load.
The system can now remain ready for operation in this state.
