NOTE: Letters in (parentheses) refer to the PARTS IDENTIFIER on page 2 and/or the PARTS ASSEMBLY on page 3. Use as needed for clarification.
FOLDING AND STORAGE
FOR STORAGE, POWERTOWER FOLDS EASILY.
53. Press the Up/Down Switch (ZY) to raise or lower the Rails (K, X). Stop about halfway up the
Tower (A). Remove the Rail Lock Screw (KK) if it has been installed.
HINT: Sit on the
Glideboard (A) and remove the Rail Lock Screw (KK) from the Rail Lock (V) if it has been
installed.
54-55. Position the Pulley Locator Brackets (C) at the fourth position on the LAT Bars (B).
56. Pull the retractable knob on the LAT Bars (B).
57-58. Lower the LAT Bars (B) into the folding position - parallel to Rails (K, X).
LAT Bar Positions
1
2
3
4
5
6
53
55
56
57
54
58
