20
NOTE: Letters in (parentheses) refer to the PARTS IDENTIFIER on page 2 and/or the PARTS ASSEMBLY on page 3. Use as needed for clarification.
FOLDING AND STORAGE (CONTINUED)
59.
Attach the center pulley to the Glideboard “D” Ring (F).
60. Lower the Folding Foot Holder (E) to the down position.
61-62. Fold the Folding Platform (I) and Telescoping Squat Stand (H). Pull the left side (as you face
the Tower (A)) retractable pin, while pushing the Telescoping Squat Stand (H) forward until
the retractable pin locks in place in the folded position.
59
60
61
62
