EFKA DA320G5351
17
Machine run with high lift for walking foot
(LHP)M11
A/31
HP
A/7
1
c2
A/21
(FSPL)
(HP)
M2
M3
A/28
A/27
A/36
M5
A/32
M4
M1
VR
FL
A/37
A/34
A/35
(ML)
(FW)
(FA)
t3
n
POS.2
A/20
POS.1
+
-
-2
0
-1
0
1/2
1
t1
c1
cb
n3
32132
n2 n10
543210
0267/LAUFH UB
c3
tHP
c4
1
n2
06
n4 n7
3212
tFA
t6
t7
FSAFSE
iFA
n7
Mark Function Parameter Control V810 V820
Double start backtack On Key S2 Key 1 Key 1
Double end backtack On Key S3 Key 2 Key 4
High lift for walking foot operational mode not stored 138 = 0
Output B high lift for walking foot 255 = 11
n2 Maximum speed 111
n3 Start backtack speed 112
n4 End backtack speed 113
n7 Trimming speed 116
n10 High lift walking speed 117
c2 Start backtack stitches forward 000
c1 Start backtack stitches backward 001
c3 End backtack stitches backward 002
c4 End backtack stitches forward 003
thP High lift walking speed run-out time 152
iFA Activation angle of the thread trimmer 250
FSA Thread tension release switch-off delay 191
FSE Thread tension release activation angle 192
tFA Stop time for thread trimmer 253
t1 Delay until speed release after start backtack 200
t3 Start delay from lifted sewing foot 202
t6 Thread wiper ON period 205
t7 Sewing foot switch-on delay after thread wiper 206
cb Number of stitches output B “high lift for walking foot” 258
