Efka DA320G5351 - Technician Level

EFKA DA320G5351
20
5.2 Technician Level
Code no. 190 with control operation
Code no. 1907 with control panel operation
Parameter Designation Unit Limits Preset for Ind.
max min 100Ω 220Ω 680Ω 1000Ω
100 SSc Number of softstart stitches stitches 254 0 2 2 1 1 A
110 n1 Positioning speed RPM 390 70 180 100 150 150 A**)
111 n2- Upper limit setting range of the maximum RPM 6000 n2_ 4800 900 1700 3500 A**)
speed
112 n3 Start backtacking speed RPM 6000 200 1700 400 800 1200 A**)
113 n4 End backtacking speed RPM 6000 200 1700 400 800 1200 A**)
114 n5 Speed after light barrier sensing RPM 6000 200 1700 400 800 1200 A**)
115 n6 Softstart speed RPM 1500 70 800 250 400 400 A**)
116 n7 Trimming speed RPM 500 70 180 100 150 150 A**)
117 n10 High lift walking speed RPM 6000 400 2000 400 800 2000 A**)
118 n12 Automatic speed for stitch counting RPM 6000 400 3000 400 800 1200 A**)
119 nSt Speed stage graduation 3 1 2 2 2 2 A
1 = linear
2 = slightly progressive
3 = highly progressive
120 nnk Whenever this speed is exceeded, RPM 6000 0 3000 3000 3000 3000 A**)
needle cooling is activated, if parameter
185 is set at “3“
121 n2_ Lower limit setting range of the maximum RPM n2- 400 400 400 400 400 A**)
speed
123 tnS End backtack synchronization time ms 500 0 0 0 0 40 A
124 nrS End backtack synchronization speed RPM 3000 200 1700 400 800 500 A**)
125 n2A Start backtack speed 2 RPM 3000 200 600 600 600 600 A
(only if parameter 284 = ON)
126 n2E End backtack speed 2 RPM 3000 200 600 600 600 600 A
(only if parameter 284 = ON)
127 AkS Audible signal On/Off 1 0 0 0 0 0 A
128 Asd Start delay, when command “start” is ms 2000 0 0 0 0 0 A**)
given by covering the light barrier
(see parameter 129)
129 ALS Automatic start by light barrier On/Off: 1 0 0 0 0 0 A
machine start by covering the light barrier, without
having heeled the pedal back to the basic position.
Additional prerequisites:
- Parameter 132 = 1
- Function “light barrier sensing” switched on on
the control panel
- Initiation of the first “normal” seam section
(pedal in the basic position)
- Cover light barrier
- Press pedal forward
- Keep pedal pressed forward
Deactivate this function by heeling the pedal back
to the basic position.
130 LSF Light barrier filter for knitted fabrics On/Off 1 0 0 0 0 0 A
131 LSd 0 = Light barrier sensing “covered” 1 0 1 1 1 1 A
1 = Light barrier sensing “uncovered”
132 LSS 0 = Machine start possible with light barrier 1 0 1 1 1 1 A
uncovered or covered.
1 = Machine start blocked with light barrier
uncovered if parameter 131 = 1.
Machine start blocked with light barrier
covered if parameter 131 = 0.
**) When programming the 3-digit or 4-digit control parameter values (without control panel), the 2-digit or 3-digit
value displayed must be multiplied by 10.
