Efka DA320G5351 - Supplier Level

EFKA DA320G5351
25
5.3 Supplier Level
Code no. 311 with control operation
Code no. 3112 with control panel operation
Parameter Designation Unit Limits Preset for Ind.
max min 100Ω 220Ω 680Ω 1000Ω
200 t1 Delay until speed release after start ms 500 0 50 50 50 50 A
backtack
201 t2 Sewing foot lift switch-on delay with half ms 500 20 80 80 80 80 A
heelback
202 t3 Start delay after disabling the sewing foot ms 500 0 80 80 120 80 A
lift signal
203 t4 Time of full power of sewing foot lifting ms 600 0 200 200 200 200 A
204 t5 Holding power for sewing foot lifting % pa. 298 1 40 40 40 40 A
1...100%
1%

low holding power
100%  high holding power
205 t6 Thread wiper time ms 2550 0 100 100 100 100 A**)
206 t7 Delay from end of thread wiper until ms 800 0 50 50 30 30 A
sewing foot lifting On
207 br1 Braking effect when modifying the preset value 55 1 20 20 20 20 A
≤ 4 stages
208 br2 Braking effect when modifying the preset value 55 1 30 30 30 30 A
≥ 5 stages
210 tSr Stop time for switching the stitch regulator ms 500 0 100 270 150 100 A
in the ornamental backtack
212 t10 Time of full power of backtacking ms 600 0 200 200 200 200 A
213 t11 Holding power for backtacking 1...100% % pa. 299 1 50 50 50 50 A
1%  low holding power
100%  high holding power
215 Zrv 0 = Last counted forward section in the start 1 0 1 1 1 1 A
backtack OFF
1 = Last counted forward section in the start
backtack ON
216 FLS 0 = Fast disabling of sewing foot lift OFF 1 0 1 1 1 1 A
1 = Fast disabling of sewing foot lift ON
219 br3 Positioning power at stop of the drive 55 1 10 10 10 10 A
220 ALF Accelerating power of the drive 55 1 20 20 20 20 A
221 dGn Speed gate 1 RPM 990 50 100 100 100 100 A
222 tGn Speed gate damping period ms 990 0 120 120 120 120 A
223 dG2 Speed gate 2 RPM 6000 200 1300 1600 1600 1600 A**)
224 dGF Speed gate 2 On/Off 1 0 1 1 1 1 A
240 in1 Selection of the input functions on socket A/7 69 0 13 13 13 13 A
for input 1
0 = No function
1 = Needle up/down
2 = Needle up
3 = Single stitch (basting stitch)
4 = Full stitch
5 = Needle to position 2
6 = Machine run blockage effective with open
contact
7 = Machine run blockage effective with closed
contact
8 = Machine run blockage unpositioned effective
with open contact
9 = Machine run blockage unpositioned effective
with closed contact
10 = Automatic speed n12 without pedal
11 = Limited speed n12 pedal controlled
**) When programming the 3-digit or 4-digit control parameter values (without control panel), the 2-digit or 3-digit
value displayed must be multiplied by 10.
