EFT agriculture frame installation manual
© 2020 Hefei EFT all rights reserved
Spray system installation
3. The water inlet is a 10MM pneumatic head,
and a 10MM water pipe is used to connect
with the pneumatic head of the bottom cover
of the tank.
4. The water outlet is 8MM pneumatic head, which
is connected with 8-8-8 tee.
3.Pass the power cord and signal cord
through the arm.
4. Pass through the arm folding parts
2. Install the water pump at the bottom of the
medicine box and tighten the M3*8 screws.
1. The head of the water pump has an arrow
pointing to the water outlet, and a round
shape is the water inlet.
