Radar installation
Pic 3
Fix the bottom
screw first
1. Front obstacle avoidance radar
6. Finished front obstacle avoidance radar.
5. Install the T-piece.
Pic 4
2. Install the radar in the universal radar adapter
board.
Pic 1
Pic 2
3. Use screws to fix on the reverse side.
4. Install the T-piece.
Pic 6
Pic 5
Then fix the
top screw
