11 EMC Tables
Page 21 / 25
Electrical fast
transients/bursts
IEC 61000-4-4
+2 kV for power
supply lines
+1 kV for
input/output lines
Not applicable
Not applicable
The test is applicable since
the EUT
does not have AC/DC power
ports and signal/
interconnecting cable
longer than 3m.
Surge
IEC 61000-4-5
+1 kV line(s) to
line(s)
+2 kV line(s) to
earth
Not applicable
Not applicable
The test is not applicable
since the EUT does not have
AC power port.
Voltage dips,
short
interruptions and
voltage
variations on
power supply
lines
IEC 61000-4-11
<5% UT
(>95% dip in UT)
for 0.5 cycle
40% UT
(60% dip in UT )
for 5 cycles
70% UT
(30% dip in UT )
for 25 cycles
<5% UT
(>95% dip in UT)
for 5 sec
Not applicable
Not applicable
Not applicable
Not applicable
The test is not applicable
since the EUT does not have
AC power port.
Power frequency
(50/60 Hz)
magnetic field
IEC 61000-4-8
3 A/m
3 A/m
Power frequency magnetic
field should be at levels
characteristic of a typical
location in a typical
commercial or hospital
environment.
Note UT is the a.c. mains voltage prior to application of the test level.
Guidance and manufacturer’s declaration – electromagnetic immunity
The Fast-Pack is intended for use in the electromagnetic environment specified below.
The customer or the user of the Fast-Pack should assure that it is used in such an
environment.
Immuni
ty test
IEC
60601 test
Comp
liance
Electromagnetic environment - guidance
