6.2.3 Upper Jaw/ Lower Jaw scan
Remove the healing abutment, adjust the scanning jaw position to the jaw
position from which the healing abutment was removed, press the button
on the scanner to activate the scanner, and scan the gum section immediately
(before gum collapse), then refer to 6.1.3 to complete the scanning of the
healing abutment jaw and the opposite jaw
6.2.4 Scanning of the scanning rod
1) Click , Switch to implant;
2) Click , Circle the portion of the implant, and the circled area is
automatically removed, If you are not satisfied with the removed part, you can
continue to remove it or click to undo the removal of the previous step.
Fold , the circled area would be extended outward for a certain distance,
the remaining part would be locked, Select the area around the gum portion
that needs to be locked to lock so that the locked area is not affected by soft
tissue collapse when further scans are performed
Page 32 / 51
