Eighteeth Helios 500 - Clinical Guide; Restoration Process

6. Clinical Guide
6.1 Restoration process
6.1.1 User login
Startup software ，fill in Username, Password and verification code，and
click
6.1.2 New patient
Click to open the new order process: fill in the information such as Patient
NO., name, age, gender and comment, select tooth position and scan type,
Restoration( Inlay, Crown, Pontic, Other), and click to enter the scan
process.
 Scanner USB inserted into workstation, If the scanner not connect, click
6.1.3 Upper Jaw/ Lower Jaw scan
1) Select / according to the Reusable tip，select the /
，OR press the button on the scanner to select the upper jaw mode
/ lower jaw mode
Page 24 / 51
