4.6 Manual Data Logger (Optional, if included)
The standard data logger (D.L.) stores measurements in the indicator's internal
memory. Data logger is capable of storing up 50,000 lines
Each single line of data stored in the D.L. memory includes:
● The unit of measurement (Lbs, Kg, kN etc.)
● The tare condition (gross or net)
● The line number in the memory (1, 2, 3 etc.)
● Time and date of capture
Each entry is stored manually by the user by executing a command. Once the
maximum number of lines has been reached according to the memory's capacity, the
D.L. will start over and #1 and write over the previous data. The operator should
consider what the maximum realistic amount of lines needed in a weighing session
will be. For example, a perfect 10 minute Bollard Pull test requiring one measurement
every 30 seconds, would require only 20 lines.
Manual Data Logger Operation
A) Storing the load value currently displayed on the screen during system
operation:
Press DATA LOGGER and then press OK. The display will flash OK and then
revert back to the current load value. The reading has now been stored in the
D.L. memory
B) Storing a MAX reading in the D.L. memory:
Press DATA LOGGER then press MAX. The display will flash OK and then
revert back to the current load value. The current MAX reading has now been stored
in the D.L. memory. Note: MAX readings will appear as D.L. MAX under the
function (FUNCT) column when output to a PC/printer.
C) Clearing data logger memory
Press and hold the Menu/OK button until a beep is heard. Use the arrow
keys▲▼ to select DATA.L from the options menu and press OK. Use the
arrow keys▲▼ to select CLEAR
