D) Downloading the stored info to PC/serial printer:
Note that for a PC, you will need to use a terminal emulator such as
Microsoft's HyperTerminal™.
Press and hold the Menu/OK button until a beep is heard. Use the arrow
keys▲▼ to select DATA.L from the options menu and press OK. Use the
arrow keys▲▼ to select OUTPUT
Ideally, the D.L. data should be output while the handheld indicator is still connected
to the load cell. However, the indicator may be used alone to output the readings if
need be. When turning the indicator on while not connected to the load cell, wait for
the screen to show ESC. Then you may output the data with the commands above.
4.7 Automatic Data Logger (Optional, if included)
Note: The system must be equipped with the RS-232 digital output and the Real Time
Clock.
The automatic data logger (ADL) automatically logs ongoing weight values,
repeatedly, in a time interval (T) that is set by the user. Along with the weight value, a
data line includes:
● The unit of measurement (Lbs, Kg, kN etc.)
● The tare condition (gross or net)
● The line number in the memory (1, 2, 3 etc.)
● The date and time that the weight value was recorded
● Function: ADL. MX, ADL. MN, ADL. AV.
If the system includes the ADL, the display will show ADL.OF after the indicator is
turned "on". The ADL functions in time intervals (T) set by the user.
To start logging press DATA LOGGER and then ESC. Display: ADL. ON
To stop logging press DATA LOGGER and then ESC. Display: ADL. OFF
