Once the system is unloaded, press OK. The display will flash WAIT for a few
seconds and then L.VALU (load value). This means that the load of a known weight
intended for calibration is ready to be applied.
Once the known weight has been applied (lifted), press OK. The display will show
APPLY followed by the max capacity of the system. Using the arrow keys ▲▼, set
the load value you intend to use for the calibration. If no key is pressed for 8 seconds,
the system will exit out of calibration mode and you will have to start again from the
beginning. Once the load value on the display matches that of the known weight
currently loaded, press OK. The display will flash WAIT and then OK. This means
the system has successfully been adjusted and the display will return to the standard
measuring screen.
At any time, you may press ◀ ESC to exit out of the calibration process. The display
will read OK and then revert back to the main measuring screen.
Multi Point Calibration:
Access the Menu:
Press and hold the Menu/OK button until a beep is heard
Using the arrow keys ▲▼ scroll to CALIBR. and press OK
The system will display SEL. ID (Select ID) and then will display ID. X (X will be the
ID of the load cell to be calibrated)
Using the▲▼ arrows will allow you to change the ID
Press Menu/OK
The system will display CODE?
Press ESC + Menu/OK simultaneously until you hear the beep.
The system will display CODE?
Quickly press TARE.
The display will show the current units in use e.g. Lbs, M. TONS etc. and will then
display LOAD.0.
At this point all weight/force must be removed from the system.
Once the system is unloaded, press OK.
The display will flash WAIT for a few seconds and then L.VALU (load value).
