4.4 RS-232 Digital Output Communication Data
(Optional, if included)
Possible baud rates: 9,600 - 19,200 - 38,400 - 115,200.
Length: 8 bits
Stop bits: 1 bit
Paring bit: none
Data output modes:
The RS-232 output on Ron systems has two modes of data output that are selectable
by the user: on demand and continuous stream.
The first will send a signal at a rate of about once per second when in use. The
second will send data only when there is a change in value detected by the indicator.
Mode Selection
Press and hold the Menu/OK button until a beep is heard
Use the arrow keys▲▼ to select RS232 from the options menu and press OK.
Use the arrow keys again and select the desired output mode:
D. MAND (on demand)
CONT. (continuous stream)
CHNGS. (upon value change)
Press OK. The display will show OK and revert back to the options menu. Press ESC
again to exit the options menu.
On demand mode:
To output data to a PC/printer when the RS-232 is set to on demand mode, simply
press OK/Menu while a load measurement is displayed.
Continuous mode:
There are two continuous modes. Each system is factory set to one or the other.
1. Continuous - unconditional constant flow(default): the displayed value will be
output at a rate of about once per second.
2. Changes - upon value change: the displayed value will only be output when there is
a change in the reading. If there is a steady change in value, a reading will be output at
