Time Interval (T) selection
Press and hold the Menu/OK button until a beep is heard. Use the arrow keys▲▼ to
select DATA.L, press Menu/OK. Use the arrow keys▲▼and select T.VALUE
Press: OK
Display: DAY
Press: ENTER
Display: 0000 – The two digits on the left will be blinking. Use the arrows keys to
select the number of days.
Press: ENTER
Display: OK, then HOUR
Press: ENTER
Display: 0000 - Now the two digits on the right will be blinking. Use the arrow keys
to select the hours.
This procedure continues, enabling the user to select the time interval (T) by selecting:
Days (up to 31) and/or
Hours (up to 24) and/or
Minutes (up to 60) and/or
Seconds (up to 60)
Once the selection is completed, press ESC to exit and return to the options menu.
4.8 Multiple Wire Rope Falls (Optional, if included)
Enter into the options menu by following the instructions in section 4. Scroll to
MULTI and press ENTER. This display will show the number of times the load value
will be multiplied by (number of rope falls). Use the arrow keys ▲▼ to change the
number (1-20). Press ENTER. The display will flash OK, then the number selected,
and will then revert back to the options menu. Select another option or press ESC to
exit the options menu.
This function is designed to enable the system to be used when the load cell is
connected to a single load suspending cable in a multi-cable suspended loading. An
example would be when the load cell is connected to the dead end of a multiple wire
rope falls crane. The multi option helps the user by multiplying the measured weight
by the number of wire ropes the load is actually suspended by.
The load cell senses one wire rope fall in a crane reeving of four wire rope falls; the
system will multiply the sensed load by four and display the result.
