EINHELL TC-SM 2131 Dual User Manual

GB
- 35 -
Caution - Read the operating instructions to reduce the risk of inquiry
Wear ear-muff s. The impact of noise can cause damage to hearing.
Wear safety goggles. Sparks generated during working or splinters, chips and dust emitted by the de-
vice can cause loss of sight.
Wear a breathing mask. Dust which is injurious to health can be generated when working on wood
and other materials. Never use the device to work on any materials containing asbestos!
Caution! Risk of injury! Do not reach into the running saw blade.
Warning! The adjustable stop rails are secured by hex screws.
To make miter cuts (with the saw head inclined or the turntable set at an angle), the adjustable stop rails
must be fi xed at an outer position.
For 45° crosscuts to the left, the left stop rail must be pushed outwards and screwed tight.
For 45° crosscuts to the right, the right-hand stop rail must be pushed outwards and screwed tight.
To make 90° crosscuts, the adjustable stops rail must be fi xed at the inner position!
Anl_TC_SM_2131_Dual_SPK8.indb 35Anl_TC_SM_2131_Dual_SPK8.indb 35 10.07.2018 08:16:3810.07.2018 08:16:38

EINHELL TC-SM 2131 Dual Specifications

General

Idle speed (max)	5000 RPM
Sound power level	104 dB
Miter setting (left)	45 °
Sound pressure level	93 dB
Input power	1800 W
Power source	AC
Blade bore	30 mm
Blade diameter	210 mm

Weight and Dimensions

Depth	717 mm
Width	455 mm
Height	393 mm
Weight	11000 g
