Page #23 background imageLoading...
Page #23 background image
GB
- 23 -
Danger!
When using the equipment, a few safety pre-
cautions must be observed to avoid injuries and
damage. Please read the complete operating
instructions and safety regulations with due care.
Keep this manual in a safe place, so that the in-
formation is available at all times. If you give the
equipment to any other person, hand over these
operating instructions and safety regulations as
well. We cannot accept any liability for damage
or accidents which arise due to a failure to follow
these instructions and the safety instructions.
1. Safety regulations
The corresponding safety information can be
found in the enclosed booklet.
Warning!
Read all the safety information, instructions,
illustrations and technical data provided on
or with this power tool. Failure to adhere to the
following instructions may result in electric shock,
re and/or serious injury.
Keep all the safety information and instruc-
tions in a safe place for future use.
Special information about the laser
Caution! Laser radiation
Do not look into the beam
Laser class 2
VORSICHT ! - LASERSTRAHLUNG !
Nicht in den Strahl blicken!
Laserspezifikation
Laser Klasse 2
Ǹ: 650 nm; P
0
ƓʸÃ
Ä·¹¾ʽʷʿʹʼƖʸ
Never look directly into the laser path.
Never direct the laser beam at reflecting
surfaces or persons or animals. Even a low
output laser beam can inflict injury on the eye.
Caution: It is vital to follow the work proce-
dures described in these instructions. Using
the equipment in any other way may result in
hazardous exposure to laser radiation.
Never open the laser module.
It is prohibited to carry out any modifications
to the laser to increase its power.
The manufacturer cannot accept any liability
for damage due to non-observance of the
safety information.
2. Layout and items supplied
2.1 Layout (Fig. 1-17)
1. Handle
2. On/O switch
3. Release lever
4. Machine head
5. Saw shaft lock
6. Adjustable blade guard
7. Saw blade
8. Clamping device
9. Locking screw for stop rail
10. Workpiece support
11. Fixed stop rail
12. Table insert
13. Adjustable foot
14. Locking screw
15. Pointer (turntable)
16. Scale (turntable)
17. Turntable
18. Fixed saw table
19. Scale (miter)
20. Pointer (miter)
21. Locking lever
22. Sawdust bag
23. Discharge opening
24. Locking screw for drag guide
25. Retaining pin
26. Adjustment screw for stop 90°
27. Knurled screw for cutting depth limiter
28. Stop for cutting depth limiter
29. Adjustment screw for stop 45° to the left
30. Adjustment screw for stop 45° to the right
31. Flange bolt
32. Outer ange
33. Button
34. Adjustable stop rail
35. Laser
36. Removable stop rail
37. On/O switch for laser
38. Transport handle
39. Socket head screw 5mm for workpiece sup-
port
40. Hex key 5mm
41. Hex key 6mm
42. Adjustment screw for stop rail
43. Cover plate
44. Screw for cover
45. Knob for adjusting the turntable
Anl_TC_SM_2534_1_Dual_SPK9.indb 23Anl_TC_SM_2534_1_Dual_SPK9.indb 23 10.12.2019 13:23:4810.12.2019 13:23:48

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the EINHELL TC-SM 2534/1 Dual and is the answer not in the manual?

EINHELL TC-SM 2534/1 Dual Specifications

General IconGeneral
Input power2350 W
Power sourceAC
AC input voltage230-240 V
AC input frequency50 Hz
Idle speed (max)4000 RPM
Cutting width (90°)340 mm
Miter setting (left)-45 °
Miter setting (right)45 °
Blade bore30 mm
Blade diameter250 mm
Saw blade included-
Number of blade teeth48
Dust extractionYes
Weight and Dimensions IconWeight and Dimensions
Weight14300 g
Package depth575 mm
Package width795 mm
Package height460 mm
Package weight19350 g
