Fundamental Concepts and Operations 72
Overview of Toolbar Function Keys
The function keys are located in the toolbar, and enable user actions. The function keys
that appear vary according to the screen or program that is currently selected.
Function keys enabling basic actions are described in the following table.
The following function keys are available from the Running screen:
Name of Key Action Notes
OK Confirms a selection or an
entered parameter
If the selection involves parameters
that are out of the permitted range,
the
OK key is disabled.
Prime Initiates priming Appears in the Attention screen, after
the Prime function has been selected.
Mute/Unmute Silences/unsilences the
speaker
Appears when any alarm is triggered.
The speaker unmutes automatically
after 2 minutes.
Back Displays the previous screen
Exit Returns to either the Start Up
screen, or to the screen
displaying current infusion
parameters
In situations when the
Back key and
the Exit key will take users to the
same screen, only the Exit key is
displayed.
Name of Key Action Notes
Lock Locks the screen or the
pump
For more information, refer to Locking
the Screen on page 194 and Activating
Patient Lockout on page 195.
Press to Unlock
screen
Unlocks the screen
Press to Unlock
Patient
Unlocks the pump Unlocking the screen requires a
password.
