Sapphire Infusion Pump User Manual73
Overview of Icons
Icons that frequently appear on the Indicators Bar and the Main Display are described
in the following table. In addition, some alarms appear with their own icons.
Request Pause/
Pause Bolus
Pauses an infusion or a bolus For more information, refer to Pausing
Infusions on page 192.
Request Continue/
Continue Bolus
Resumes a paused infusion
or a bolus
View/Edit Displays a list of infusion
parameters to be viewed or
edited
Bolus Delivers a bolus during
continuous, PCA and PCEA
modes
Icon Meaning Notes
>
Indicates that the parameter
immediately adjacent to the icon can be
viewed and updated directly from the
Main Display.
To initiate the update, touch the
box in which the icon appears.
Rate of the infusion.
Volume to be infused.
Name of Key Action Notes
