Eizo FLEXSCAN EV2456 User Manual

13
Chapter 2 Basic Adjustment/Setting
2-3. Switching Display Modes (Color Modes)
This product is preinstalled with color modes for various display purposes.
Switch the mode according to the purpose and content for display. This allows the monitor to display
images in a manner appropriate to the display content.
●
Display Modes
Color Mode Purpose
User1
User2
Select either of these modes to set a user-dened display mode.
sRGB
This mode is suitable for matching color reproduction with peripheral devices that
support sRGB, such as when printing photos taken using a digital camera.
Paper
This mode uses color tones and contrast similar to that of paper to produce a printed
paper effect. It is suitable for displaying images from media such as books and
documents.
Movie
This mode displays moving images brightly and with a clear-cut three-dimensional
appearance. It is suitable for playing back video content.
DICOM
Select this mode to simply display medical purpose digital images based on DICOM
Part 14
.
Attention
• This is not intended to be used for diagnostic purposes.
Note
• “Screen InStyle” allows you to select the color mode automatically according to the application in use.
• In Paper mode, the amount of blue light emitted from the screen is reduced by changing the color tone and
controlling the brightness.
2-4. Conserving Energy
This monitor is equipped with EcoView functions to enable users to conserve energy.
Use this function to curtail unnecessary power consumption and save on electricity expenses. Saving
power also reduces carbon dioxide emissions.

Eizo FLEXSCAN EV2456 Specifications

General

3D	No
HD type	WUXGA
Pixel pitch	0.27 x 0.27 mm
Screen shape	Flat
Display diagonal	24.1 \
Separate H/V sync	Yes
Display resolution	1920 x 1200 pixels
Display technology	LED
Native aspect ratio	16:10
Vertical scan range	55 - 76 Hz
Horizontal scan range	31 - 81 kHz
Viewable size, vertical	324 mm
Contrast ratio (typical)	1000:1
Display number of colors	16.78 million colors
Viewable size, horizontal	518.4 mm
Display brightness (typical)	350 cd/m²
Supported graphics resolutions	640 x 480 (VGA), 720 x 400, 800 x 600 (SVGA), 1024 x 768 (XGA), 1280 x 1024 (SXGA), 1600 x 1200 (UXGA), 1680 x 1050 (WSXGA+), 1920 x 1200 (WUXGA)
USB hub version	3.2 Gen 1 (3.1 Gen 1)
Headphone connectivity	3.5 mm
USB upstream port type	USB Type-B
USB Type-A downstream ports quantity	2
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Energy efficiency scale	A to G
Power consumption (max)	44 W
Power consumption (standby)	0.5 W
Power consumption (typical)	13.5 W
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	20 - 80 %
Sustainability certificates	CB, CCC, CE, China RoHS, ENERGY STAR, EPEAT Bronze, Federal Communications Commission (FCC), ICES, PSE, RCM, RoHS, TCO, TUV, UKCA, VCCI, WEEE, cTUVus
Tilt up angle range	- °
Number of OSD languages	9
Panel mounting interface	100 x 100 mm
On Screen Display (OSD) languages	CHI (SIMPL), CHI (TR), DEU, ENG, ESP, FRE, ITA, JPN, SWE
RMS rated power	2 W
Certification	CE, UKCA, CB, TÜV/GS, TÜV/Ergonomics (including ISO 9241-307), TCO Certified Generation 9, EPEAT 2018 (US), TÜV/Blue Low Light Content, TÜV/Flicker Free, RCM, cTÜVus, FCC-B, CAN ICES-3 (B), TÜV/S, PSE, VCCI-B, EPA ENERGY STAR, RoHS, WEEE, China RoHS, CCC
Product color	Black
Cables included	AC, USB
Harmonized System (HS) code	85285210

Weight and Dimensions

Depth (with stand)	190 mm
Height (with stand)	351.4 mm
Weight (with stand)	5700 g
Depth (without stand)	45.5 mm
Width (without stand)	531 mm
Height (without stand)	341.9 mm
Weight (without stand)	3700 g
