Chapter 3 Advanced Adjustment/Setting
Function Setting Range Description
Input Color Format Auto
*2
YUV 4:2:2
*3
YUV 4:4:4
*3
YUV
*4
RGB
The color format of the input signal can be specied.
Try changing this setting if colors are not displayed
correctly.
Note
• This can only be set during DisplayPort or HDMI
input.
• This setting is required when a DVI device is
connected to the monitor via the HDMI connector
port using a DVI-HDMI conversion connector.
• This setting is xed to “RGB” when receiving a DVI
signal from the DVI connector.
*2 Only enabled when input signal information according to which the setting can be automatically
determined is detected
*3 Only enabled during HDMI input
*4 Only enabled during DisplayPort input
Function Setting Range Description
Input Range Auto
Full
Limited
Depending on the PC, black and white of the video
level of the signal output to the monitor may be limited.
If a limited signal is displayed on the monitor, black
will appear faint and white will appear dull, leading to a
reduction in contrast. The output range of such signals
can be extended to match the actual contrast ratio of
the monitor.
• “Auto” Automatically identies the brightness
range of the input signal and displays the image
accordingly.
• “Full” Extension of the signal output range is not
performed.
• “Limited” Extends the signal output range through
0 to 255 and displays the image.
Note
• This can only be set during DisplayPort or HDMI
input.
• This setting is xed to “Full” for DVI signal input.
Function Description
Analog
Adjustment
*5
Auto
Screen
Adjust
Screen ickering, display position, and size can be adjusted automatically.
Selecting “Auto Screen Adjust” displays a message. Select “Yes” to enable this
function.
Note
• The automatic screen adjustment function works correctly when an image is
fully displayed over the entire displayable area of the screen. It does not work
properly in the following cases:
- When an image is only displayed on part of the screen (command prompt
window, for example)
- When a black background (wallpaper, etc.) is used
Also, this function may not work properly with some graphic boards.
• When a signal is input into the monitor for the rst time or when a resolution
or vertical/horizontal scan frequency not used before is set, adjustment is
performed automatically (only for signals with a resolution of 800×600 (SVGA)
or higher).

Eizo FLEXSCAN EV2456 Specifications

General

3D	No
HD type	WUXGA
Pixel pitch	0.27 x 0.27 mm
Screen shape	Flat
Display diagonal	24.1 \
Separate H/V sync	Yes
Display resolution	1920 x 1200 pixels
Display technology	LED
Native aspect ratio	16:10
Vertical scan range	55 - 76 Hz
Horizontal scan range	31 - 81 kHz
Viewable size, vertical	324 mm
Contrast ratio (typical)	1000:1
Display number of colors	16.78 million colors
Viewable size, horizontal	518.4 mm
Display brightness (typical)	350 cd/m²
Supported graphics resolutions	640 x 480 (VGA), 720 x 400, 800 x 600 (SVGA), 1024 x 768 (XGA), 1280 x 1024 (SXGA), 1600 x 1200 (UXGA), 1680 x 1050 (WSXGA+), 1920 x 1200 (WUXGA)
USB hub version	3.2 Gen 1 (3.1 Gen 1)
Headphone connectivity	3.5 mm
USB upstream port type	USB Type-B
USB Type-A downstream ports quantity	2
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Energy efficiency scale	A to G
Power consumption (max)	44 W
Power consumption (standby)	0.5 W
Power consumption (typical)	13.5 W
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	20 - 80 %
Sustainability certificates	CB, CCC, CE, China RoHS, ENERGY STAR, EPEAT Bronze, Federal Communications Commission (FCC), ICES, PSE, RCM, RoHS, TCO, TUV, UKCA, VCCI, WEEE, cTUVus
Tilt up angle range	- °
Number of OSD languages	9
Panel mounting interface	100 x 100 mm
On Screen Display (OSD) languages	CHI (SIMPL), CHI (TR), DEU, ENG, ESP, FRE, ITA, JPN, SWE
RMS rated power	2 W
Certification	CE, UKCA, CB, TÜV/GS, TÜV/Ergonomics (including ISO 9241-307), TCO Certified Generation 9, EPEAT 2018 (US), TÜV/Blue Low Light Content, TÜV/Flicker Free, RCM, cTÜVus, FCC-B, CAN ICES-3 (B), TÜV/S, PSE, VCCI-B, EPA ENERGY STAR, RoHS, WEEE, China RoHS, CCC
Product color	Black
Cables included	AC, USB
Harmonized System (HS) code	85285210

Weight and Dimensions

Depth (with stand)	190 mm
Height (with stand)	351.4 mm
Weight (with stand)	5700 g
Depth (without stand)	45.5 mm
Width (without stand)	531 mm
Height (without stand)	341.9 mm
Weight (without stand)	3700 g
