Eizo FlexScan EV2750 User Manual

- 22 -
Chapter 3
Advanced Adjustment/Setting
Function
Color Mode
(Functions that can be adjusted differ
depending on the color mode.)
√: Adjustable -: Not adjustable
Setting Range Description Note
User1
User2
sRGB Paper Movie
DICOM
Screen Selection Left Screen
Right Screen
Whole Screen
Enabled only during PbyP display.
Select the application range for each setting of
the color adjustment.
When using PbyP display, select this range rst.
• “Left Screen”
The setting is applied only to the left screen.
• “Right Screen”
The setting is applied only to the right
screen.
• “Whole Screen”
The setting will be applied to both the left
and right screens.
For details on PbyP, see “2-2.
Switching Input Signals” (page
14).
Color Mode √ √ √ √ √ User1
User2
sRGB
Paper
Movie
DICOM
Select the desired mode according to the
monitor application.
The color setting status can also be adjusted
according to personal preference. Select the
mode for adjustment and perform adjustment
using the relevant functions.
• For details on the adjustment
status of each mode, see “2-
3. Switching Display Modes
(Color Modes)” (page 15).
Brightness √ √ √ √ - 0 to 100 The screen brightness is adjusted by changing
the brightness of the backlight (light source from
the LCD back panel).
• If the image is too dark even
when the brightness is set to
100, adjust the contrast.

Eizo FlexScan EV2750 Specifications

General

3D	No
DDC/CI	Yes
Pixel pitch	0.233 x 0.233 mm
Aspect ratio	16:9
Screen shape	Flat
Display surface	Matt
Display diagonal	27 \
Display technology	LED
Viewable size, vertical	335.7 mm
Contrast ratio (typical)	1000:1
Display number of colors	16.78 million colors
Viewable size, horizontal	596.7 mm
Digital vertical frequency	59 - 61 Hz
Digital horizontal frequency	31 - 89 kHz
Display brightness (typical)	350 cd/m²
Supported graphics resolutions	1920 x 1080 (HD 1080), 2560 x 1440
USB hub version	3.2 Gen 1 (3.1 Gen 1)
DVI-D ports quantity	1
Headphone connectivity	3.5 mm
VGA (D-Sub) ports quantity	0
USB Type-A downstream ports quantity	2
RMS rated power	2 W
Certification	TCO Displays 7, TUV/E, TUV/GS, RCM, CE, CB, cTUVus, FCC-B, TUV/S, VCCI-B, RoHS, WEEE, CCC, EAC
Product color	White
Market positioning	-
Pivot angle	0 - 90 °
Tilt angle range	-5 - 35 °
Number of OSD languages	11
Panel mounting interface	100 x 100 mm
On Screen Display (OSD) languages	CHI (SIMPL), CHI (TR), DEU, ENG, ESP, FRE, ITA, JPN, SWE
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	67 W
Annual energy consumption	39 kWh
Power consumption (standby)	0.5 W
Power consumption (typical)	22 W
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	20 - 80 %
Sustainability certificates	EPEAT Gold, ENERGY STAR
Cables included	AC, DisplayPort, USB
Bundled software	EIZO ScreenManager Pro EIZO ScreenSlicer

Weight and Dimensions

Depth (with stand)	245 mm
Height (with stand)	545.2 mm
Weight (with stand)	7900 g
Depth (without stand)	48.5 mm
Width (without stand)	611.6 mm
Height (without stand)	359 mm
Weight (without stand)	5100 g
