Eizo FlexScan EV2750 User Manual

- 23 -
Chapter 3
Advanced Adjustment/Setting
Function
Color Mode
(Functions that can be adjusted differ
depending on the color mode.)
√: Adjustable -: Not adjustable
Setting Range Description Note
User1
User2
sRGB Paper Movie
DICOM
Contrast √ - - √ - 0 to 100 The brightness of the screen is adjusted by
varying the video signal level.
• A contrast of 50 displays every
color gradation.
• When adjusting the monitor,
it is recommended to perform
brightness adjustment, which
does not lose gradation
characteristics, prior to
contrast adjustment.
• Perform contrast adjustment in
the following cases.
- If the image is too dark even
when the brightness is set
to 100. (Set the contrast to
higher than 50.)
Temperature √ - √ √ - Off
4000 K to
10000 K
(specied in
500 K units,
includes 9300 K)
Adjust the color temperature.
The color temperature is normally used to
express the hue of “White” and/or “Black” with
a numerical value. The value is expressed in
degrees “K” (Kelvin).
The screen becomes reddish at low color
temperatures and bluish at high color
temperatures, similar to the temperatures of a
ame. A gain preset value is set for each color
temperature setting value.
• The value shown in “K” is
available only as a reference.
• “Gain” allows you to perform
more advanced adjustment.
• If set to “Off”, the image is
displayed in the preset color of
the monitor (Gain: 100 for each
RGB channel).
• When the gain is changed,
the color temperature setting
changes to “Off”.
Gamma √ - - - - 1.8
2.0
2.2
2.4
Adjust the gamma.
While the brightness of the monitor varies
depending on the input signal, the variation
rate is not proportional to the input signal.
Maintaining the balance between the input
signal and brightness of the monitor is referred
to as “Gamma correction”.
• If “Paper” is selected for
the color mode, “Paper” is
displayed for the gamma value.
• If “DICOM” is selected for
the color mode, “DICOM” is
displayed for the gamma value.

Eizo FlexScan EV2750 Specifications

General

3D	No
DDC/CI	Yes
Pixel pitch	0.233 x 0.233 mm
Aspect ratio	16:9
Screen shape	Flat
Display surface	Matt
Display diagonal	27 \
Display technology	LED
Viewable size, vertical	335.7 mm
Contrast ratio (typical)	1000:1
Display number of colors	16.78 million colors
Viewable size, horizontal	596.7 mm
Digital vertical frequency	59 - 61 Hz
Digital horizontal frequency	31 - 89 kHz
Display brightness (typical)	350 cd/m²
Supported graphics resolutions	1920 x 1080 (HD 1080), 2560 x 1440
USB hub version	3.2 Gen 1 (3.1 Gen 1)
DVI-D ports quantity	1
Headphone connectivity	3.5 mm
VGA (D-Sub) ports quantity	0
USB Type-A downstream ports quantity	2
RMS rated power	2 W
Certification	TCO Displays 7, TUV/E, TUV/GS, RCM, CE, CB, cTUVus, FCC-B, TUV/S, VCCI-B, RoHS, WEEE, CCC, EAC
Product color	White
Market positioning	-
Pivot angle	0 - 90 °
Tilt angle range	-5 - 35 °
Number of OSD languages	11
Panel mounting interface	100 x 100 mm
On Screen Display (OSD) languages	CHI (SIMPL), CHI (TR), DEU, ENG, ESP, FRE, ITA, JPN, SWE
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	67 W
Annual energy consumption	39 kWh
Power consumption (standby)	0.5 W
Power consumption (typical)	22 W
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	20 - 80 %
Sustainability certificates	EPEAT Gold, ENERGY STAR
Cables included	AC, DisplayPort, USB
Bundled software	EIZO ScreenManager Pro EIZO ScreenSlicer

Weight and Dimensions

Depth (with stand)	245 mm
Height (with stand)	545.2 mm
Weight (with stand)	7900 g
Depth (without stand)	48.5 mm
Width (without stand)	611.6 mm
Height (without stand)	359 mm
Weight (without stand)	5100 g
