Eizo FlexScan EV2750 User Manual

- 26 -
Chapter 3
Advanced Adjustment/Setting
Function
Input Signal
(The setting range of each function
differs depending on the input signal.)
√: Settable -: Not settable
Setting Range Description Note
DisplayPort
HDMI
DVI
PC
signal
Video
signal
Picture Expansion √ √ - √ Full Screen
Aspect Ratio
Dot by Dot
The screen size of the monitor display can be
changed.
• “Auto”
The monitor automatically changes the screen
size according to the aspect ratio and resolution
information from the PC.
• “Full Screen”
Images are stretched to full screen. Since
aspect ratios are not maintained, images may be
distorted in some cases.
• “Aspect Ratio”
Images are enlarged to full screen without
changing the aspect ratio. Since aspect ratios are
maintained, blank horizontal or vertical borders
may appear.
• “Dot by Dot”
Displays the image at the set resolution or size
specied by the input signal.
• Example settings
- Full Screen
- Aspect Ratio
- Dot by Dot (input signal)
- - √ - Auto
Full Screen
Aspect Ratio
Dot by Dot
Input Color Format √ - - - Auto
YUV
RGB
The color format of the input signal can be specied.
Try changing this setting if colors are not displayed
correctly.
• This setting is required
when a DVI device is
connected to the monitor
via the HDMI connector
port using a DVI-HDMI
conversion connector.
• This setting is xed to “RGB”
when receiving a DVI signal
from the DVI connector.
- √ - - YUV 4:2:2
YUV 4:4:4
RGB
- - √ - Auto
YUV 4:2:2
YUV 4:4:4
RGB

Eizo FlexScan EV2750 Specifications

General

3D	No
DDC/CI	Yes
Pixel pitch	0.233 x 0.233 mm
Aspect ratio	16:9
Screen shape	Flat
Display surface	Matt
Display diagonal	27 \
Display technology	LED
Viewable size, vertical	335.7 mm
Contrast ratio (typical)	1000:1
Display number of colors	16.78 million colors
Viewable size, horizontal	596.7 mm
Digital vertical frequency	59 - 61 Hz
Digital horizontal frequency	31 - 89 kHz
Display brightness (typical)	350 cd/m²
Supported graphics resolutions	1920 x 1080 (HD 1080), 2560 x 1440
USB hub version	3.2 Gen 1 (3.1 Gen 1)
DVI-D ports quantity	1
Headphone connectivity	3.5 mm
VGA (D-Sub) ports quantity	0
USB Type-A downstream ports quantity	2
RMS rated power	2 W
Certification	TCO Displays 7, TUV/E, TUV/GS, RCM, CE, CB, cTUVus, FCC-B, TUV/S, VCCI-B, RoHS, WEEE, CCC, EAC
Product color	White
Market positioning	-
Pivot angle	0 - 90 °
Tilt angle range	-5 - 35 °
Number of OSD languages	11
Panel mounting interface	100 x 100 mm
On Screen Display (OSD) languages	CHI (SIMPL), CHI (TR), DEU, ENG, ESP, FRE, ITA, JPN, SWE
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	67 W
Annual energy consumption	39 kWh
Power consumption (standby)	0.5 W
Power consumption (typical)	22 W
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	20 - 80 %
Sustainability certificates	EPEAT Gold, ENERGY STAR
Cables included	AC, DisplayPort, USB
Bundled software	EIZO ScreenManager Pro EIZO ScreenSlicer

Weight and Dimensions

Depth (with stand)	245 mm
Height (with stand)	545.2 mm
Weight (with stand)	7900 g
Depth (without stand)	48.5 mm
Width (without stand)	611.6 mm
Height (without stand)	359 mm
Weight (without stand)	5100 g
