- 27 -
Chapter 3
Advanced Adjustment/Setting
Function
Input Signal
(The setting range of each function
differs depending on the input signal.)
√: Settable -: Not settable
Setting Range Description Note
DisplayPort
HDMI
DVI
PC
signal
Video
signal
Range Extension - - Auto
On
Off
Depending on the PC, black and white of the video
level of the signal output to the monitor may be
limited. If a limited signal is displayed on the monitor,
black will appear faint and white will appear dull,
leading to a reduction in contrast. The output range
of such signals can be extended to match the actual
contrast ratio of the monitor.
Auto”
Automatically identies the brightness range
of the input signal and displays the image
accordingly.
“On”
Extends the signal output range through 0 to 255
and displays the image.
“Off
Extension of the signal output range is not
performed.
Example settings
- Off
- On
This setting is xed to “Off
for DVI signal input.
- - - On
Off
Sound Source - - - Stereo Mini Jack
DisplayPort
The audio source can be changed when receiving
DisplayPort signal input or HDMI signal input.
This setting is xed to
“Stereo Mini Jack” when
receiving DVI signal input or
HDMI (PC signal) input.
- - - Stereo Mini Jack
HDMI

Other manuals for Eizo FlexScan EV2750

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Eizo FlexScan EV2750 and is the answer not in the manual?

Eizo FlexScan EV2750 Specifications

General IconGeneral
3DNo
DDC/CIYes
Pixel pitch0.233 x 0.233 mm
Aspect ratio16:9
Screen shapeFlat
Display surfaceMatt
Display diagonal27 \
Display technologyLED
Viewable size, vertical335.7 mm
Contrast ratio (typical)1000:1
Display number of colors16.78 million colors
Viewable size, horizontal596.7 mm
Digital vertical frequency59 - 61 Hz
Digital horizontal frequency31 - 89 kHz
Display brightness (typical)350 cd/m²
Supported graphics resolutions1920 x 1080 (HD 1080), 2560 x 1440
USB hub version3.2 Gen 1 (3.1 Gen 1)
DVI-D ports quantity1
Headphone connectivity3.5 mm
VGA (D-Sub) ports quantity0
USB Type-A downstream ports quantity2
RMS rated power2 W
CertificationTCO Displays 7, TUV/E, TUV/GS, RCM, CE, CB, cTUVus, FCC-B, TUV/S, VCCI-B, RoHS, WEEE, CCC, EAC
Product colorWhite
Market positioning-
Pivot angle0 - 90 °
Tilt angle range-5 - 35 °
Number of OSD languages11
Panel mounting interface100 x 100 mm
On Screen Display (OSD) languagesCHI (SIMPL), CHI (TR), DEU, ENG, ESP, FRE, ITA, JPN, SWE
AC input voltage100 - 240 V
AC input frequency50 - 60 Hz
Power consumption (max)67 W
Annual energy consumption39 kWh
Power consumption (standby)0.5 W
Power consumption (typical)22 W
Operating temperature (T-T)5 - 35 °C
Operating relative humidity (H-H)20 - 80 %
Sustainability certificatesEPEAT Gold, ENERGY STAR
Cables includedAC, DisplayPort, USB
Bundled softwareEIZO ScreenManager Pro EIZO ScreenSlicer
Weight and Dimensions IconWeight and Dimensions
Depth (with stand)245 mm
Height (with stand)545.2 mm
Weight (with stand)7900 g
Depth (without stand)48.5 mm
Width (without stand)611.6 mm
Height (without stand)359 mm
Weight (without stand)5100 g
