Eizo FLEXSCAN S2433W User Manual

44
Chapter 5 Reference
5-5 Preset Timing
The following table shows factory preset video timing (for analog signal only).
Mode Dot clock
Frequency
Polarity
Horizontal: kHz
Vertical: Hz
VGA 640×480@60Hz 25.2 MHz
Horizontal 31.47 Negative
Vertical 59.94 Negative
VGA TEXT
720×400@70Hz
28.3 MHz
Horizontal 31.47 Negative
Vertical 70.09 Positive
VESA 640×480@73Hz 31.5 MHz
Horizontal 37.86 Negative
Vertical 72.81 Negative
VESA 640×480@75Hz 31.5 MHz
Horizontal 37.50 Negative
Vertical 75.00 Negative
VESA 800×600@56Hz 36.0 MHz
Horizontal 35.16 Positive
Vertical 56.25 Positive
VESA 800×600@60Hz 40.0 MHz
Horizontal 37.88 Positive
Vertical 60.32 Positive
VESA 800×600@72Hz 50.0 MHz
Horizontal 48.08 Positive
Vertical 72.19 Positive
VESA 800×600@75Hz 49.5 MHz
Horizontal 46.88 Positive
Vertical 75.00 Positive
VESA 1024×768@60Hz 65.0 MHz
Horizontal 48.36 Negative
Vertical 60.00 Negative
VESA 1024×768@70Hz 75.0 MHz
Horizontal 56.48 Negative
Vertical 70.07 Negative
VESA 1024×768@75Hz 78.8 MHz
Horizontal 60.02 Positive
Vertical 75.03 Positive
VESA 1152×864@75Hz 108.0 MHz
Horizontal 67.50 Positive
Vertical 75.00 Positive
VESA 1280×960@60Hz 108.0 MHz
Horizontal 60.00 Positive
Vertical 60.00 Positive
VESA 1280×1024@60Hz 108.0 MHz
Horizontal 63.98 Positive
Vertical 60.02 Positive
VESA 1280×1024@75Hz 135.0 MHz
Horizontal 79.98 Positive
Vertical 75.03 Positive
VESA 1600×1200@60Hz 162.0 MHz
Horizontal 75.00 Positive
Vertical 60.00 Positive
VESA 1600×1200@65Hz 175.0 MHz
Horizontal 81.25 Positive
Vertical 65.00 Positive
VESA 1600×1200@70Hz 189.0 MHz
Horizontal 87.50 Positive
Vertical 70.00 Positive
VESA 1600×1200@75Hz 202.5 MHz
Horizontal 93.75 Positive
Vertical 75.00 Positive
VESA CVT
1680×1050@60Hz
146.3 MHz
Horizontal 65.29 Negative
Vertical 59.95 Positive
VESA CVT
1920×1200@60Hz
193.3 MHz
Horizontal 74.56 Negative
Vertical 59.89 Positive
VESA CVT RB
1920×1200@60Hz
154.0 MHz
Horizontal 74.04 Positive
Vertical 59.95 Negative
Attention
• Display position may be deviated
depending on the PC connected,
which may require screen adjustment
using Adjustment menu.
• If a signal other than those listed in
the table is input, adjust the screen
using the Adjustment menu. However,
screen display may still be incorrect
even after the adjustment.
• When interlace signals are used, the
screen cannot be displayed correctly
even after screen adjustment using the
Adjustment menu.

Eizo FLEXSCAN S2433W Specifications

General

Pixel pitch	0.270 x 0.270 mm
Aspect ratio	16:10
Response time	6 ms
Display diagonal	24.1 \
Display resolution	1920 x 1200 pixels
Vertical scan range	55 - 76 Hz
Horizontal scan range	31 - 94 kHz
Viewable size diagonal	611 mm
Contrast ratio (typical)	1000:1
Display number of colors	16.78 million colors
Digital vertical frequency	59 - 61 Hz
Digital horizontal frequency	31 - 76 kHz
Display brightness (typical)	360 cd/m²
Display viewable area (HxV)	518.4 x 324 mm
HDCP	Yes
I/O ports	DisplayPort
USB hub version	2.0
Headphone connectivity	3.5 mm
USB Type-A downstream ports quantity	3
RMS rated power	1 W
Certification	TCO Displays 5.0, EPEAT Gold, TÜV/Ergonomics ( ISO 13406-2), TÜV/GS, c-Tick, CE, CB, UL (cTÜVus), CSA (cTÜVus), FCC-B, Canadian ICES-003-B, TÜV/S, VCCI-B, EPA Energy Star, RoHS, WEEE, EIZO Eco Products 2009
Product color	Black
Market positioning	-
Compliance industry standards	VESA DDC 2B
Power consumption (typical)	95 W
Power consumption (PowerSave)	1.5 W
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth (with stand)	208.5 mm
Height (with stand)	538 mm
Weight (with stand)	10200 g
Depth (without stand)	85 mm
Width (without stand)	566 mm
Height (without stand)	367 mm
Weight (without stand)	7200 g
