When the cooking cycle is completed the “HACCP” function is automatically disabled.
DISPLAY “HACCP” DATA (ON PC)
To display on the PC the parameters of an executed cookign cycle:
- press the “START/STOP” key for few seconds and switch off the oven
- remove the “USB pen drive” from the oven and insert it in the “USB port” of the PC
- open the desired “file” in the “USB pen drive”
Important
All the data concerning the cooking done on the same day are contained in the same “HACCP”
file. The “HACCP” file is automatically renamed after another “HACCP” file is created on the
following day, highlighting the date when the cooking has been done.
The “HACCP” data must be interpreted with the aid of the following key:
KEY
C1
START OF COOKING
C2
COOKING CORRECTLY ENDED
C3
COOKING INTERRUPTED WITH START/STOP KEY OR DUE TO AN ALARM
AL1
ALARM: OPEN DOOR
AL2
ALARM: THE CORE PROBE HAS BROKEN DOWN DURING COOKING
AL3
ALARM: THE TEMPERATURE PROBE IS FAULTY
AL4
ALARM: MOTOR
AL5
ALARM: SAFETY THERMOSTAT
AL9
ALARM: RESISTORS ARE NOT CONNECTED
R
RECIPE NAME
R: MAN
MANUALLY SET RECIPE
F0
TYPE OF MANUAL RECIPE
F1
FIRST COURSES
F2
SECOND COURSES
F3
FISH
F4
GAME
F5
BREAD
F6
VEGETABLES
F7
DESSERTS
F8
EXTRA
T1
TEMPERATURE DETECTED IN THE COOKING CHAMBER
T2
TEMPERATURE DETECTED BY THE CORE PROBE
D1
THE DOOR WAS OPENED DURING COOKING
D2
THE DOOR WAS CLOSED DURING COOKING
