eka MKF 464 BM - User Manual

fffffssdsdsdsdsdsELECTRONIC BLACK MASK OVENS
TRANSLATION OF ORIGINAL INSTALLATION AND
MAINTENANCE MANUAL
ELECTRONIC BLACK MASK OVENS
MKF 464 BM- MKF 416 BM - MKF 511 BM - MKF 611 CBM
MKF 623 CBM - MKF 664 BM – MKF 616 BM – MKF 621 BM – MKF 711 BM
MKF 1011 CBM - MKF 1064 BM – MKF 1016 BM – MKF 1111 BM
MKF 1021 BM – MKF 1664 BM – MKF 2011 BM

Summary

General Information and Safety

Intended Use and Modifications

Appliance for professional use by skilled personnel; modifications are hazardous.

Maintenance Safety Precautions

Disconnect from power supply and cool before maintenance or cleaning.

Installer Instructions: General Setup

Storage, Transportation, and Unpacking

Store above 0°C, transport in packaging, check for damage during unpacking.

Protective Film Removal and Disposal

Remove protective film using solvent; dispose of packaging according to regulations.

Site Placement Requirements

Ensure adequate space, ventilation, floor support, and alignment for installation.

Installer Instructions: Specific Placement

Table Top Oven Placement

Place tabletop ovens horizontally on stable surface with adjustable feet.

Stacking Ovens Safely

Use only the specified "STACKING KIT" for stacking ovens to prevent damage.

Floor Standing Oven Placement

Position floor-standing ovens on level floor; ensure trolley movement and alignment.

Electrical Connection Procedures

Main Electrical Connection Standards

Comply with local regulations for voltage, frequency, and system capacity matching appliance specifications.

Power Cable Replacement Guide

Replace power supply cable with identical electrical characteristics and correct terminal board connection.

Mains Connection Types and Wiring

Water Inlet Connections

Humidification;Steam Water Inlet

Use flexible hose, mechanical filter, and stopcock for water inlet for humidification/steam.

Water Drain Systems

Automatic Washing Water Inlet

Connect to water mains via quick fitting, flexible hose, filter, and stopcock.

Floor Oven Drain Configuration

Convey drain pipe to floor drain with a 25mm air gap or wall-mounted discharge.

Tabletop Oven Drain Configuration

Convey pipe to floor drain or collection cup with 30cm height difference or 25mm air gap.

Steam Discharge Management

Maintenance and Safety Inspections

Accessing Internal Components for Service

Instructions for removing side panels or back cover to access internal components.

Safety Thermal Device Functionality

Appliance has a safety thermostat to prevent overheating; requires technician reset.

Component Maintenance and Adjustments

Electronic Circuit Protection Fuses

Replace blown fuses with equivalent ones after resolving the issue; technician task.

Cooking Chamber Gasket Replacement

Replace gasket by removing the old one and inserting the new one into the seat.

Door Handle Closure Adjustment

Adjust handle nose position to ensure proper door closure and alignment.

Gasket Seal Checks and Operational Safety

Gasket Seal Adjustment Procedures

Adjust hinges or handle nose to improve gasket seal; check for steam leaks during operation.

Appliance Handling and Residual Risks

Do not use handle to move; disconnect power before maintenance; check wheeled model stability.

Troubleshooting Oven Faults

Understanding Appliance Alarms

Support, Warranty, and Disposal

Technical Support and Contact Information

Contact dealer or support centre for calibration, testing, and repair services.

Appliance Disposal and Recycling

Dispose of the appliance at appropriate recycling centres according to regulations.

Conventional Warranty Terms and Conditions

Warranty covers original faults for professional customers within specified timeframes.

Spare Parts and Legal Information

Spare Parts Availability Policy

Spare parts are available for a maximum of 24 months from the date of sale to the dealer.

Applicable Law and Dispute Resolution

Supply relationships governed by Italian law; disputes settled by the Court of Padua.
