Eko-Vimar Orlanski Orlan - Key Boiler Components Identification

EKO BOILER MANU AL
5
Two views of the gasification chamber and nozzle burning at near 2,000 degrees, F.
9
1
Important
Components
10
1.) Controller
2
2.) Loading Door
8
3.) Secondary Air Adjust
4.) Ash Door
6
5.) Forced Draft Fan
6.) Primary Burn Chamber
7.) Secondary Chamber
8.) Heat Exchanger Tubes
9.) Supply Water Outlet
5
10.) Bypass Damper Lever
3
7
4
