Elan 310 - 230 V System

Owner’s Manual
32
7
7
.
.
6
6
.
.
2
2
.
.
2
2
3
3
0
0
V
V
S
S
Y
Y
S
S
T
T
E
E
M
M
The boat is optionally equipped with a 230 V electrical circuit. The shore power plug is
located in the cockpit. In addition to the battery charger, the circuit also comprises sockets
for 230 V consumers.
WARNING: - Never work on the electrical installation without disconnecting the
power supply. An electrical shock can cause fire.
- Before connecting the cable on the shore, connect it to the boat first.
- Disconnect the cable after use.
- First swich off the main switch in the boat, then disconnect the cable on
the shore and last, disconnect it on the boat.
- Do not soak the catches of the cable in the water.
- Do not modify any terminals of the electrical cable.
- Never modify an electrical installation.
C
C
O
O
N
N
T
T
R
R
O
O
L
L
P
P
A
A
N
N
E
E
L
L
2
2
3
3
0
0
V
V
Figure 15
